The Tran-X powered by Quaife LSD is a multiple plate limited slip differential. It features two ramp blocks sandwiching two planet carrier pins which sit in the radius between the leading and trailing ramp angle. As torque is applied to the differential’s input, the pins ride up their respective leading ramps, pushing the blocks apart and increasing the transfer of torque across the axle.
The angle of this ramp determines how quickly this transfer occurs within the LSD. An angle of 35 degrees allows the blocks to be pushed apart more readily than a 55 degree setting, resulting in a more aggressive differential locking action. Plus, the preload setting dictates the contact friction between the plates themselves. The higher the preload, the more rapidly friction increases between the plates, creating a more aggressive locking action. Combined with the ramp angles, the preload allows subtle adjustments to the torque transfer characteristics allowing users to alter the dynamic balance of their car.
Typical settings for a lightweight track car would be 45/90, allowing progressive application of power for optimum acceleration. Some Tran-X powered by Quaife differentials feature dual ramp blocks, allowing ramp angles to be changed between two combinations, for example track and fast road settings (disassembly and reassembly of the LSD is required). We also offer a less aggressive ‘super-lightweight’ plate setting (preload 10-15 lbsft) for certain road and kit car applications to optimise performance and reduce operating noise.
3J Driveline Ltd Designed and manufactured NXG (NeXt Generation) English Lsd. The strongest, most progressive and versatile LSD unit in the market place. The 3J plate pack always run with 8 active surfaces, even in our lighter settings, giving maximum surfaces and surface area contact during use. Our new pre-load spacer helps generate the pre-load. Rather than just have the 2 or 3 settings of other units, we can 'fine tune' to particular pre-load settings complemented with our choice of ramps, to get the perfect LSD set up for you. The Bevel and planet gear pack has been designed to be the smoothest mesh, biggest and strongest tooth profile that we have ever been involved with. Eliminating the rattle, and excessive back lash of other units
